• Network Parameters
• Port Number8 × Gigabit PoE ports, 1 × Gigabit RJ45 port, and 1 × Gigabit SFP fiber optical port
• Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
• StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z
• Forwarding ModeStore-and-forward switching
• MAC Address Table4 K
• Switching Capacity20 Gbps
• Packet Forwarding Rate14.88 Mpps
• Internal Cache1.5 Mbits

• PoE Power Supply
• PoE StandardIEEE 802.3af, IEEE 802.3at
• PoE Power PinSupport 4-core power supply, and Ethernet cable 1/2/3/6 provide power supply.
• PoE PortPorts 1 to 8
• Max. Port Power30 W
• PoE Power Pudget110 W
• Max. Power Consumption120 W

• General
• ShellMetal material, fan-free design
• Gross Weight1.4 kg (3.09 lb)
• Net Weight0.6 kg (1.32 lb)
• Dimension (L × H × D)217.6 mm × 27.8 mm × 108.55 mm (8.6” × 1.1” × 4.3”)
• Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
• Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
• Operating Humidity5% to 95% (no condensation)
• Storage Humidity5% to 95% (no condensation)
• Power Supply48 VDC, 2.5 A
• Power Consumption In Idle10 W
